Lardner Park Chain Mesh Security Fencing
Hyline supplied and installed approximately 670m of galvanised chain mesh security fencing at Lardner Park in September 2026. The project included pedestrian and vehicle access gates, plus a fixed panel over a creek to complete the fence line.
The 2100mm high heavy gauge mesh is supported by cranked posts, with three Waratah barbed wires taking the overall height to 2550mm. Three 4mm helicoil cables and compression rails with diagonal wires at straining points form part of the system. The access gates use 32NB frames and swing hinges on 100NB gate posts, with the vehicle pair providing an approximately 8m opening.
Protecting the lawn required careful planning and plenty of hard work. Working alongside Lardner Park staff, the team used the farm’s loader to deliver concrete to the post holes, avoiding the lawn damage a concrete truck would have caused. The concrete was then shovelled out by hand, while the cranked posts had to be set accurately to their final height.
Despite the demanding installation, the crew started on Monday and had the site secured by Saturday morning.
Project Snapshot
- Client
- Lardner Park
- Location
- Lardner VIC
- Project Date
- September 2026
- Job Type
- Chain mesh security fencing
- Scope
- Supply and install approximately 670m of galvanised chain mesh fencing, one pedestrian gate, one pair of vehicle gates providing an approximately 8m opening, and one fixed panel over a creek
- Height
- 2100mm chain mesh, with cranked posts and barbed wire extending to 2550mm
- System
- 2100mm high 50 × 3.15mm knuckle-barb heavy gauge galvanised chain mesh, cranked posts, 3 Waratah barbed wires and 3 × 4mm helicoil cables; compression rails with diagonal wires at straining points
- Gates
- 32NB frames with swing hinges on 100NB gate posts; one pedestrian gate and one pair of vehicle gates with an approximately 8m opening
- Turnaround
- Started Monday; site secured by Saturday morning
Looking after returning customers
We value the trust our returning customers place in Hyline. For Lardner Park, that meant putting in the extra work to protect the grounds, work closely with their team and deliver a secure site within a demanding timeframe.
